Product Dimension
|
– 430 (W) * 467 (D) * 44 (H) mm
|
|
Product Model
|
– JBC161F594-Q170-S
|
|
MB Model
|
– JNF594-Q170 (Mini-itx / 170 * 170 mm)
– CPU : INTEL Core i7/i5/i3/Pentium/Celeron Processor / LGA1150
– Chipset : Intel Q170 Chipset
– Memory : 2 * DDR4 SO-DIMM / 2133 Mhz SDRAM up to 32 GB
|
|
Specs Devices
|
– 3.5” SATA Device * 4 & 2.5” SATA Device * 1
|
|
Colors
|
– Silver
|
|
Front I/O Port
|
– Power SW * 1 , Reset SW * 1
– Power LED * 1 , HDD R/W LED * 1
– USB 2.0 * 2
|
|
Rear I/O Port
|
– USB 3.0 * 6
– HDMI * 1 , DP * 1 , DVI-D * 1
– COM * 2
– RJ-45 * 2
– Mic * 1 , Line in * 1 , Line out * 1
– AC INPUT * 1
|
|
1U Power
|
– AC 90~240V input / 1U-300W / Support PFC / 190 (L) *100 (W) *40.5 (H) mm (FLEX)
|
|
FAN
|
– 4020 FAN * 4 / 7000 rpm / DC-12V-0.1A / 12 CFM
– 4038 FAN * 2 / 12000 rpm / DC-12V-0.3A / 42 CFM
|
|
Expansion Slot
|
– Mini-PCI (PCI-E) Slot * 1
|
|
Accessory
|
– Power cord * 1 , PCI-E Riser Card * 1
– User’s Manual * 1 , CD *1
– Quick Installation Guide * 1
– Screw Pack * 1
– CPU Cooler FAN (95*95*28mm) * 1
|
|
Packing
|
– Net Weight：5.8 KG
– Gross Weight：6.8 KG
– Color Box Dimension：560 (W) x 600 (D) x 140 (H) mm
|
|
Safety
|
– CE , FCC
|
|
Applications
|
– Server System
– Storage System
– NAS System
– Video Editing System
|
|
Warranty
|
–2 Year limited warranty
|
